Resolution

0.014mm

Accuracy

0.043 mm

Linearity error

0.3% FSR

Max sample rate

4 SPS

Max latency

2 seconds

Power

3.4 – 4.5 VDC (1x 3.6V LTC battery) At 5 mA

Radio frequency

2.4Ghz

Maximum distance from receiver device

5 m , (Mounting dependent)

Maximum number of devices in close proximity

30 units

Radio Frequency Conformity

IEEE 802.15.1 (ISM standard)

Size

10 mm dia x 60 mm long

Weight

10,5 grams

Antenna connector required

Hirose U.FL-LP-040

Battery connector

SURS # SM05B-SURS-TF

Mounting thread

10 mm x .75

Battery life

Dependent on SPS and Sample Period

Power

5-30 VDC, 100mA

Interface Protocol

RS-485 Modbus RTU

Protocol Baud

19200

Protocol Parity

Even

Protocol Stop Bits

1

Device Address

0x42 (may be adjusted)

Operating Temperature

4 to 55oC

Storage Temperature

-15 to 65oC (5 to 150oF)

Radio frequency

2.4Ghz

Maximum distance from sensor

5 m , (Mounting dependent)

Radio Frequency Conformity

IEEE 802.15.1 (ISM standard)

Size

15mm H x 44 W x 64 mm L

Weight

4 Oz

Connector

Phoenix Contact #1844263

Mate

Phoenix Contact #1840382
