TI德州儀器比較器
發布時間：2021-01-13 16:15:35 瀏覽：1795
TI德州儀器公司在工業上提供廣泛的低功耗、高速和高壓比較器，適用于電壓監測應用(過電壓保護或電池欠壓檢測)和事件監測的零交叉檢測(Zcd)。TI德州儀器的生產線還包括各種不同的設備，如具有集成基準的窗口比較器和比較器。
TI公司為各種汽車、工業和個人電子系統提供高性能的比較器。TI德州儀器公司的比較器包括多種產品，以滿足從超低功耗到高速的各種系統要求，以幫助客戶滿足下一種設計的性能要求。
深圳市立維創展科技有限公司，專注于TI 德州儀器品牌高端可出口產品系列新品產品，并備有現貨庫存，可當天發貨。
詳情了解TI德州儀器請點擊：/brand/57.html
或聯系我們的銷售工程師： 0755- 83642657 QQ： 2295048674
*詳情了解更多型號請聯系我們的銷售工程師。
Part number | Number of channels
(#) | Vs
(Max)
(V) | Vs
(Min)
(V) | Propagation delay time
(μs) | Vos (offset voltage @ 25 C)
(Max)
(mV) | Iq per channel
(Typ)
(mA) | Input bias current (+/-)
(Max)
(nA) | Operating temperature range
(C) | VICR
(Max)
(V) | VICR
(Min)
(V) | Approx. price
(US$) |
LM2903B | 2 | 36 | 2 | 1 | 2 | 0.2 | 25 | -40 to 125 | 34.5 | 0 | 0.05 | 1ku |
LM393B | 2 | 36 | 2 | 1 | 2 | 0.2 | 25 | -40 to 85 | 34 | 0 | 0.05 | 1ku |
LM2903B-Q1 | 2 | 36 | 2 | 1 | 2 | 0.2 | 25 | -40 to 125 | 0 | 34.5 | 0.10 | 1ku |
TLV9034 | 4 | 5.5 | 1.65 | 0.15 | 1.5 | 0.018 | 0.005 | -40 to 125 | 5.5 | 0 | 0.41 | 1ku |
TLV7032 | 2 | 6.5 | 1.6 | 3 | 8 | 0.0003 | 0.002 | -40 to 125 | 6.6 | 0 | 0.25 | 1ku |
TLV9024-Q1 | 4 | 5.5 | 1.65 | 0.15 | 1.5 | 0.018 | 0.005 | -40 to 125 | 5.5 | 0 | 0.46 | 1ku |
TLV9034-Q1 | 4 | 5.5 | 1.65 | 0.15 | 1.5 | 0.018 | 0.005 | -40 to 125 | 5.5 | 0 | 0.46 | 1ku |
LM339LV | 4 | 5.5 | 1.65 | 0.6 | 2 | 0.025 | 0.005 | -40 to 125 | 5.5 | 0 | 0.11 | 1ku |
TLV9024 | 4 | 5.5 | 1.65 | 15 | 1.5 | 0.018 | 0.005 | -40 to 125 | 5.5 | 0 | 0.41 | 1ku |
TLV3604 | 1 | 5.5 | 2.4 | 0.00085 | 5 | 13 | 5000 | -40 to 125 | 5.7 | -0.2 | 1.50 | 1ku |
TLV9022 | 2 | 5.5 | 1.65 | 0.15 | 1.5 | 0.018 | 0.005 | -40 to 125 | 5.5 | 0 | 0.30 | 1ku |
TLV9032 | 2 | 5.5 | 1.65 | 0.15 | 1.5 | 0.018 | 0.005 | -40 to 125 | 5.5 | 0 | 0.30 | 1ku |
LM393LV | 2 | 5.5 | 1.65 | 0.6 | 2 | 0.025 | 0.005 | -40 to 125 | 5.5 | 0 | 0.09 | 1ku |
TLV9022-Q1 | 2 | 5.5 | 1.65 | 0.15 | 1.5 | 0.018 | 0.005 | -40 to 125 | 5.5 | 0 | 0.35 | 1ku |
TLV9032-Q1 | 2 | 5.5 | 1.65 | 0.15 | 1.5 | 0.018 | 0.005 | -40 to 125 | 5.5 | 0 | 0.35 | 1ku |
TLV7042 | 2 | 6.5 | 1.6 | 3 | 8 | 0.0003 | 0.002 | -40 to 125 | 6.6 | 0 | 0.25 | 1ku |
LM339LV-Q1 | 4 | 5.5 | 1.65 | 0.6 | 2 | 0.025 | 0.005 | -40 to 125 | 5.5 | 0 | --- |
LM393LV-Q1 | 2 | 5.5 | 1.65 | 0.6 | 2.5 | 0.025 | 0.005 | -40 to 125 | 5.5 | 0 | --- |
TLV7022 | 2 | 6.5 | 1.6 | 0.26 | 8 | 0.0047 | 0.002 | -40 to 125 | 6.6 | 0 | 0.26 | 1ku |
TLV7012 | 2 | 6.5 | 1.6 | 0.26 | 8 | 0.0047 | 0.002 | -40 to 125 | 6.6 | 0 | 0.26 | 1ku |
TLV4011 | 1 | 6 | 1.3 | 5 | 9 | 0.003 | 25 | -40 to 85 | 6 | 1.3 | 0.35 | 1ku |
TLV4062 | 2 | 5.5 | 1.5 | 5.5 | 6 | 0.002 | 15 | -40 to 125 | 5.5 | 1.5 | 0.44 | 1ku |
TLV4082 | 2 | 5.5 | 1.5 | 5.5 | 6 | 0.002 | 15 | -40 to 125 | 5.5 | 1.5 | 0.35 | 1ku |
TLV7031 | 1 | 6.5 | 1.6 | 3 | 8 | 0.000335 | 0.002 | -40 to 125 | 6.6 | 0 | 0.18 | 1ku |
TLV7031-Q1 | 1 | 6.5 | 1.6 | 3 | 8 | 0.000335 | 0.002 | -40 to 125 | 6.6 | 0 | 0.21 | 1ku |
TLV3201 | 1 | 5.5 | 2.7 | 0.047 | 5 | 0.04 | 0.05 | -40 to 125 | 5.7 | -0.2 | 0.40 | 1ku |
TLV7041-Q1 | 1 | 6.5 | 1.6 | 3 | 8 | 0.000335 | 0.002 | -40 to 125 | 0 | 0 | 0.21 | 1ku |
TLV3501 | 1 | 5.5 | 2.7 | 0.0045 | 6.5 | 3.2 | 0.01 | -40 to 125 | 5.7 | -0.2 | 1.02 | 1ku |
TLV1704 | 4 | 36 | 2.2 | 0.56 | 2.5 | 0.055 | 15 | -40 to 125 | 36 | 2.2 | 0.85 | 1ku |
TLV7044 | 4 | 6.5 | 1.6 | 3 | 8 | 0.0003 | 0.002 | -40 to 125 | --- | 6.6 | 0.45 | 1ku |
TLV7034 | 4 | 6.5 | 1.6 | 3 | 8 | 0.000315 | 0.002 | -40 to 125 | 6.6 | 0 | 0.45 | 1ku |
TLV4062-Q1 | 2 | 5.5 | 1.5 | 5.5 | 6 | 0.002 | 15 | -40 to 125 | 5.5 | 1.5 | 0.52 | 1ku |
TLV4082-Q1 | 2 | 5.5 | 1.5 | 5.5 | 6 | 0.002 | 15 | -40 to 125 | 5.5 | 1.5 | 0.41 | 1ku |
TLV6703-Q1 | 1 | 18 | 1.8 | 18 | 2 | 0.006 | 25 | -40 to 125 | 6.5 | 0 | 0.61 | 1ku |
TLV4011-Q1 | 1 | 6 | 1.3 | 5 | 9 | 0.003 | 25 | -40 to 125 | 6 | 1.3 | 0.41 | 1ku |
TLV6700-Q1 | 2 | 18 | 1.8 | 18 | 2 | 0.006 | 15 | -40 to 125 | 6.5 | 0 | 0.72 | 1ku |
TLV4051 | 1 | 5.5 | 1.6 | 0.36 | 4 | 0.002 | 5 | -40 to 125 | 5.5 | 1.6 | 0.34 | 1ku |
TLV4031 | 1 | 5.5 | 1.6 | 0.36 | 4 | 0.002 | 5 | -40 to 125 | 5.5 | 1.6 | 0.34 | 1ku |
TLV4041 | 1 | 5.5 | 1.6 | 0.36 | 4 | 0.002 | 5 | -40 to 125 | 5.5 | 1.6 | 0.34 | 1ku |
TLV1805-Q1 | 1 | 40 | 3.3 | 0.25 | 4.5 | 0.15 | 0.5 | -40 to 125 | 0 | 0 | 0.31 | 1ku |
TLV1805 | 1 | 40 | 3.3 | 0.25 | 4.5 | 0.15 | 0.5 | -40 to 125 | 0 | 0 | 0.26 | 1ku |
TLV1704-SEP | 4 | 36 | 2.2 | 0.56 | 2.5 | 0.055 | 15 | -55 to 125 | 36 | 2.2 | --- |
TLV4021 | 1 | 5.5 | 1.6 | 0.36 | 4 | 0.002 | 5 | -40 to 125 | 5.5 | 1.6 | 0.34 | 1ku |
TLV6700 | 2 | 18 | 1.8 | 18 | 2 | 0.006 | 15 | -40 to 125 | 6.5 | 0 | 0.61 | 1ku |
TLV6703 | 1 | 18 | 1.8 | 18 | 2 | 0.006 | 25 | -40 to 125 | 6.5 | 0 | 0.52 | 1ku |
TLV6710 | 2 | 36 | 1.8 | 9.9 | 2 | 0.008 | 25 | -40 to 125 | 1.7 | 0 | 0.78 | 1ku |
TLV6713 | 1 | 36 | 1.8 | 10 | 2 | 0.008 | 25 | -40 to 125 | 1.7 | 0 | 0.70 | 1ku |
TLV7041 | 1 | 6.5 | 1.6 | 3 | 8 | 0.000335 | 0.002 | -40 to 125 | 6.6 | 0 | 0.18 | 1ku |
TLV7021 | 1 | 5.5 | 1.6 | 0.26 | 8 | 0.005 | 0.005 | -40 to 125 | 5.6 | 0 | 0.16 | 1ku |
TLV1701-Q1 | 1 | 36 | 2.2 | 0.46 | 3.2 | 0.055 | 15 | -40 to 125 | 36 | 2.2 | 0.39 | 1ku |
TLV7011 | 1 | 5.5 | 1.6 | 0.26 | 8 | 0.005 | 0.005 | -40 to 125 | 5.6 | 0 | 0.16 | 1ku |
TLV3201-Q1 | 1 | 5.5 | 2.7 | 0.047 | 5 | 0.04 | 0.05 | -40 to 125 | 5.7 | -0.2 | 0.47 | 1ku |
TLV3202-Q1 | 2 | 5.5 | 2.7 | 0.047 | 5 | 0.04 | 0.05 | -40 to 125 | 5.7 | -0.2 | 0.59 | 1ku |
TLV1704-Q1 | 4 | 36 | 2.2 | 0.56 | 2.5 | 0.055 | 15 | -40 to 125 | 36 | 2.2 | 1.01 | 1ku |
TLV1702-Q1 | 2 | 36 | 2.2 | 0.56 | 2.5 | 0.055 | 15 | -40 to 125 | 36 | 2.2 | 0.63 | 1ku |
TLV1701 | 1 | 36 | 2.2 | 0.56 | 2.5 | 0.055 | 15 | -40 to 125 | 36 | 2.2 | 0.33 | 1ku |
TLV1702 | 2 | 36 | 2.2 | 0.56 | 2.5 | 0.055 | 15 | -40 to 125 | 36 | 2.2 | 0.54 | 1ku |
TLV3691 | 1 | 6.5 | 0.9 | 24 | 15 | 0.000075 | 0.1 | -40 to 125 | 6.6 | -0.1 | 0.33 | 1ku |
